Treating Tipped and Ectopically Positioned Molars
Clinical approaches to uprighting malpositioned permanent molars.
Clinical approaches to uprighting malpositioned permanent molars.
The presence of tipped and/or ectopically positioned permanent molars is a common dental problem, and while affected dentition may not be initially detectable, it will present during routine radiographic examinations. An ectopic eruption of a permanent first molar often results in either an unerupted or partially erupted tooth. In these cases, the permanent first molar tips mesially, and is thus unable to erupt due to physical entrapment by the distal contour of the deciduous second molar.
An ill-fitting stainless steel crown on a second deciduous molar can also prevent the permanent first molar from erupting by creating a “ledge” that entraps it. Figure 1A through Figure 1C illustrate an ectopically erupting tooth #3 molar that is caught under the ledge created by the stainless steel crown on #A, and its subsequent uprighting with an elastomeric separator and placement of a maxillary space maintenance device.
The ectopic position or tipping of an unerupted or partially erupted second permanent molar, and the subsequent inability of that tooth to erupt into the dental arch, is also frequently seen in clinical practice. This is caused by tooth bud malposition of a second molar or crowding from the presence of a third molar in close proximity to the second molar. Regardless of the etiology, a number of negative outcomes may result, including:
- Failure of eruption or partial eruption of the permanent second molar (Figure 2)
- Gingival inflammation around the partially erupted molar or pericornitis involving the unerupted second molar (Figure 3)
- An osseous defect (most likely anatomical in nature) on the mesial root of the unerupted second molar (Figure 4)
- Resorption of a root surface by the crown of an unerupted second molar (Figure 5)
- High incidence of caries both to the distal surface of the first molar and the mesial surface of the partially erupted second molar (Figure 6)
- Difficulty in restoring caries lesions (Figure 7)
- Hypereruption of an opposing tooth (Figure 8)
The potential problems with partially erupted or unerupted second molars are commonly seen when adolescent patients are transitioning from a pediatric dental practice to a general dental office.
Pericornitis is often associated with partially erupted second molars, especially in the mandibular arch. If recommended by the dentist, dental auxiliaries can treat this problem with debridement and irrigation with various therapeutic agents, including saline, diluted hydrogen peroxide or chlorhexidine.
Orthodontic solutions are focused on uprighting the second molar with fixed orthodontic appliances, which, due to their position, can be difficult. It is also challenging to clean the area while the tooth movement is occurring with appliances in place. The dental team needs to educate these patients about proper techniques for keeping these areas clean and minimizing problems stemming from inflammation and lack of plaque control.
Figure 9 through Figure 12 illustrate how second molars can be uprighted orthodontically. In this case, the treatment was completed over 21 months. Note the proximity of the appliances to the tissue, and the change in the interproximal bone level between #30 and #31 as the second molar uprights. Excellent oral hygiene is paramount to the success of this treatment.
ERUPTED TIPPED MOLARS
When a second deciduous molar is lost prematurely in patients with mixed dentition and clinicians fail to provide space maintenance (Figure 13), or the second deciduous molar is ankylosed and the first molar tips mesially over the ankylosed tooth, serious consequences can result. With the loss of the second deciduous molar and tipping of the permanent first molar, the options are to accept the presence of the unerupted second bicuspid; extract the unerupted second bicuspid (which can harm the posterior occlusion of the affected side and osseous support of the adjacent teeth); or upright the permanent first molar and erupt the second bicuspid — which, in an older patient, may require a surgical exposure and forced eruption.
In the case illustrated in Figure 13 through Figure 17, the mandibular first molar was orthodontically uprighted and, fortunately, the second bicuspid erupted on its own. The uprighting procedure of opening the space and eruption of the second bicuspid took approximately 15 months of orthodontic treatment with fixed appliances. The restored occlusion is demonstrated in Figure 17. Other than restoring proper occlusion, the height of the bone level on the mesial surface of the mesial root of #30 rose with the eruption of #29 (compare Figure 13 to Figure 17). The prognosis for continued periodontal health is also improved, as the interseptal bone width is now more at the occlusal level for both the mandibular first molar and first bicuspid.
- Tipped and/or ectopically positioned permanent molars are a common dental problem and will present during radiographic examinations.
- The ectopic position or tipping of an unerupted or partially erupted second permanent molar, and the subsequent inability of that tooth to erupt into the dental arch, is also frequently seen in clinical practice.
- Potential problems with partially erupted or unerupted second molars are commonly observed when adolescent patients are transitioning from a pediatric practice to a general dental office.
- Serious consequences can result if a second deciduous molar is lost prematurely in patients with mixed dentition and the clinician fails to provide space maintenance (Figure 13), or if the second deciduous molar is ankylosed and the first molar tips mesially over the ankylosed tooth.
- Ankylosed second deciduous molars are more problematic than ankylosed first primary molars because the first permanent molar will often tip mesially, and either prevent nonsurgical extraction of the ankylosed second deciduous molar or eventually block eruption of a second premolar.
- In the case of a tipped second molar into the first molar extraction space, the uprighting of the second molar can be described as “facilitative orthodontics” or “adjunctive orthodontics” — therapy in which orthodontic tooth movement facilitates prosthodontic restoration of the missing tooth.
- Correcting the tipping of a second molar most often involves orthodontic uprighting with either removable or fixed appliances.
ANKYLOSED PRIMARY MOLARS
The presence of ankylosed primary molars also presents a problem in the management of tipped molars. Ankylosed second deciduous molars have long been a concern for orthodontists, because they cause mesial tipping of the permanent first molar distal to the submerged second molar.1,2 There are various theories regarding the etiology of ankylosis of the primary molar, but the current consensus is that the infra-occluded primary molar, in addition to allowing tipping of the adjacent permanent molar, can also lead to significant bone loss on the root of the adjacent permanent molar.3
Ankylosed second deciduous molars are more problematic than ankylosed first primary molars because the first permanent molar will often tip mesially, and either prevent nonsurgical extraction of the ankylosed second deciduous molar or eventually block eruption of a second premolar.
Whether intervention in the presence of ankylosed primary molars is necessary is controversial. Kurol reported that nonintervention is appropriate in most cases.4,5 Negative outcomes in the adult dentition when ankylosed primary molars are not addressed have also been reported, however.6 The decision to intervene should be made on a case-by-case basis after evaluating all relative information.
TIPPED MOLARS IN ADULTS
Tipped molars in adult patients are problematic, as well. The presence of a nonreplaced permanent first molar with tipping and lingual rotation of the second molar into the extraction space is the most common presentation. In the case of a tipped second molar into the first molar extraction space, the uprighting of the second molar can be described as “facilitative orthodontics” or “adjunctive orthodontics” — therapy in which orthodontic tooth movement facilitates prosthodontic restoration of the missing tooth. Facilitative orthodontics is not used solely to improve the path of insertion for a prosthesis, however, as it is also indicated to establish physiologic alveolar crest topography, often on the mesial root surface of the tipped molar. The uprighting of these tipped molars can sometimes eliminate the need for periodontal surgery.6
In 1923, Hirschfeld first reported the theory that the relationship of a tooth to the alveolar process could affect both the size and shape of the supporting periodontal tissues.7 In the 1950s, practitioners began to hypothesize that the tooth could be used as an attachment to move and remodel bone, in other words, molar uprighting could move the bone coronally as the tooth moved into a more upright position.6
Brown first published about the resolution of a mesial vertical defect anterior to a tipped second molar in 1973. As many tipped second molars create a pseudopocket due to excessive tissue, a vertical bony defect does not necessarily follow. Entrapment of bacteria, however, often promotes the growth of periodontal pathogens — which then leads a vertical bony defect.8
The loss of a mandibular permanent first molar without replacement often leads to:
- Mesial tipping of the second molar
- Lingual rotation of the second molar
- Supereruption of the opposing maxillary first molar (if there is no opposing tooth contact)
- Bunching of the tissue on the mesial surface of the tipped molar — with accompanying tissue inflammation
- Vertical osseous defect on the mesial surface of the mesial root of the second molar
- Unsatisfactory positioning of the mandibular second molar for use as an abutment of a bridge to replace the missing molar
Correcting the tipping of a second molar most often involves orthodontic uprighting with either removable or fixed appliances. Maintaining periodontal health around the tooth that is being uprighted is critical. Mobility of the tooth being uprighted in an adult patient is almost unavoidable, but, by maintaining good oral hygiene in this area, inflammation may be limited and mobility reduced.
Whether the uprighting of a molar resolves a bony defect, or if the bone merely flattens as the tipped molar is uprighted, is still unclear. Although this subject has been studied for years, it is still uncertain if the bone merely follows its attachment to the tooth and moves vertically as the tooth uprights — or if the reduction in pathogens due to the uprighting of the tooth and good oral hygiene cause the change in the alveolar topography.
Mihram and Murphy advocate for molar uprighting to resolve vertical bony defects.6 Lundgren et al found that molars tipped as long as 30 years did not increase risk for moderate periodontal disease at the mesial surface.9 Wehrbein and Deidrich found no mesiomarginal bone level differences between tipped and upright molars in young adults. However, they observed a higher level of supragingival and subgingival plaque, more inflammatory cells and capillaries, and a lower density of gingival fibers mesial to the tipped molars. The plaque-induced inflammatory infiltrates on the tipped molars apparently affected the bone levels on the distal aspect of teeth mesial to the tipped molars.10 Orthodontic uprighting may improve these conditions.
Tipped molars, whether unerupted, partially erupted or completely erupted, can cause significant oral health issues. Once these conditions are properly diagnosed, orthodontics can be used to successfully address problems associated with malpositioned permanent molars, thus improving patients’ overall oral health.
- Biederman W. Etiology and treatment of tooth ankylosis. Am J Orthodont. 1962;48:670–684.
- Darling Al, Levers BG. Submerged human deciduous molars and ankylosis. Arch Oral Biol. 1973;18:1021–1040.
- Jenkins FR, Nichol RE. Atypical retention of infraoccluded primary molars with permanent successor teeth. Eur Arch Paediatr Dent. 2008;9:51–95.
- Kurol J, Koch G. The effect of extraction of infraoccluded deciduous molars: A longitudinal study. Am J Orthodont. 1985;87:46–55.
- Kurol J, Olson L. Ankylosis of primary molars — a future periodontal threat to the first permanent molars? Eur J Orthod. 1991;13:404–409.
- Mihram WL, Murphy NC. The Orthodontist’s Role in 21st Century Periodontic-Prosthodontic Therapy. Available at: http://www.researchgate.net/publication/228624991_The_Orthodontist’s_Role_in_21st_Century_Periodontic-Prosthodontic_Therapy. Accessed December 1, 2015.
- Hirschfeld I. A study of skulls in the American Museum of Natural History in relation to periodontal disease. J Dent Res. 1923;5:241–265.
- Brown IS. The effect of orthodontic therapy on certain types of periodontal defects: I. Clinical findings. J Periodontol. 1973;44:742–756.
- Lundgren D, Kurol J, Thorstensson B, Hugoson A. Periodontal conditions around tipped and upright molars in adults. An intra-individual retrospective study. Eur J Orthod. 1992;14:449–455.
- Wehrbein H, Deidrich P. Mesio-marginal findings at tilted molars. A histological-histomorphometric study. Eur J Orthod. 2001;23:663–670.
